JM12-PLC （Engine hood riveting machine）

Characteristics:

■Applied new automatic technologies

■ Programmable, simple and reliable

■ With X, Y, Z axis program control

■Workpiece clamping automatically

■6.5 inch LCD touch screen

■ Digital Pressure Sensor

■Multi-safety sensors

■Single head or multi-head available

■Hydraulic or pneumatic as optional

■Manual, semi auto, automatic functions

■Display current pressure

■Plexiglass safety covered around the machine

■Automatic shutdown of time-lapse

■Can reserve the connector mouth for synchronize clamp

Specification:

1. Max.pressure                              20Kn

2. Max.processing ability              Φ12mm

3. Cylinder strocke                        30mm,60mm,80mm, as optional

4. Riveting pin length                    50mm, 85mm, 120mm, as optional

5. Two-dimensional bench            600mmx350mm

6.  Moves:

       X-direction                                     600mm

       Y-direction                             300mm

       z-direction                              70mm

7. Positioning accuracy                ±0.05mm

8. Forming shape                          Semi-round,flate,reticulate,dish-shaped etc.

9. Physical size                              1500mmx1000mmx1800mm

10.Net weight                               1000KG
